Shenzhou Generator DIesel SZN224 of China Manufactory

FOB Reference Price:Get Latest Price
US $600-5,000 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
300 Set/Sets per Month
Port:
FUZHOU
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China (Mainland)
Brand Name:
None
Model Number:
SZN224
Output Type:
AC Three Phase
Speed:
1500/1800RPM
Frequency:
50HZ / 60HZ
Rated Power:
34~83KW
Rated Voltage:
120~690V
Rated Current:
Depend
Rated Capacity:
42.5~103.8KVA
Gross Weight:
385KG
Net Weight:
360KG
Package:
Plywood case/wooden case
Certificate:
CE, ISO9001
Warranty:
One Year
OEM Service:
Yes
Keyword:
generator diesel
Packaging & Delivery
Packaging Details
Plywood case/wooden case
Delivery Time
Shipped in 20 days after payment

Shenzhou Generator DIesel SZN224 of China Manufactory

Product Description

Features:



1. Optional permanent magnecitc generators providing invariable excitation on all occasions.



2. Easy to be connected with power network or other generators. Standard 2/3 pitch windings check excessive midline current.



3. Balanced rotor. Single or two sealed ball bearings.



4. Convenient installation and maintenance with easy access to terminal, rotating diodes and coupling bolts.



5. Wide range of Flange adaptor and single bearing couping disc.



6. Meet leading industry and Marine standards. Special voltage generators can be manufactured accoring to end users' requirement.



Single-phase generators minimum voltage can be 110V. Three-phase generators maximum voltage can be 690V.



ModelOutput (kW) 50Hz/4pole/400VOutput (kW) 60Hz/4pole/480V
KVAKWKVAKW
SZN164A8.16.58.97.2
SZN164B11.08.812.19.7
SZN164C13.510.814.911.9
SZN164D16.012.817.614.1
SZN184E22.51824.819.8
SZN184F27.52230.324.2
SZN184G31.32534.427.5
SZN184H37.53041.333.0
SZN184J42.53446.837.4
SZN224C42.53446.837.4
SZN224D50.04055.044.0
SZN224E60.04866.052.8
SZN224F72.55879.863.8
SZN224G85.06893.574.8
SZN274C100.080110.088.0
SZN274D120.096132.0105.6
SZN274E140.0112154.0123.2
SZN274F160.0128176.0140.8
SZN274G180.0144198.0158.4
SZN274H200.0160220.0176.0
SZN274J230.0184253.0202.4
SZN274K250.0200275.0220.0
SZN314C250.0200275.0220.0
SZN314D295.0236324.5259.6
SZN314E325.0260357.5286.0
SZN314F380.0304418.0334.4
SZN354C450.0360495.0396.0
SZN354D500.0400550.0440.0
SZN354E600.0480660.0528.0
SZN354F670.0536737.0589.6
